| Cooling | Liquid |
| Cylinders Displacement | 999 cc |
| Drive System Type | On-Demand True AWD/2WD/VersaTrac Turf Mode |
| Engine Braking System (EBS) | EDA: Engine Deceleration Assist |
| Engine Type | ProStar 1000 4-Stroke DOHC Twin Cylinder |
| Fuel System/Battery | Electronic Fuel Injection |
| Horsepower | 100 HP |
| Transmission/Final Drive | Automatic PVT P/R/N/L/H |
| Bed Box Dimensions (L x W x H) | 27.5 x 43.1 x 11.6 in (69.8 x 109 x 29.5 cm) |
| Estimated Dry Weight | 1,690 lb (767 kg) |
| Front/Rear Rack or Box Capacity | 600 lb (272 kg) Rear Dumping Box |
| Fuel Capacity | 9.5 gal (35.9 L) |
| Ground Clearance | 13.5 in (34.3 cm) |
| Overall Vehicle Size (L x W x H) | 118.2 x 64 x 77" (300 x 162.5 x 190.5 cm) |
| Payload Capacity | 1,100 lb (499 kg) |
| Person Capacity | 2 |
| Wheelbase | 83 in (211 cm) |
| Front/Rear Brakes | 4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers |
| Parking Brake | Park In-Transmission |
| Front Tires | 30 x 10-15; Pro Armor Crawler XGF |
| Rear Tires | 30 x 10-15; Pro Armor Crawler XG |
| Wheels | 15" Aluminum |
| Front Shocks | Walker Evans Velocity Series Shocks |
| Front Suspension | Long Travel, High Clearance Dual A-Arm with Stabilizer Bar, 14" (35.6 cm) Travel |
| Rear Shocks | Walker Evans Velocity Series Shocks |
| Rear Suspension | Long Travel, High Clearance Dual Arm IRS with Stabilizer Bar, 14" (35.6) Travel |
| Cargo System | Lock & Ride |
| Ingress / Egress | Half Doors Standard |
| Instrumentation | Dual-sweep Analog Dials w/ 4" LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder Light, Gear Indicator, DC Outlet Factory Choice: RIDE COMMAND™ 7” Glove-Touch Display: Digital Instrumentation, Built-In GPS, Mapping, Vehicle-to-Vehicle w/ Group Ride, Follow the Leader, & Messenging. Front & Rear On-board Cameras. Bluetooth & USB Smartphone Connectivity, AM/FM & Weather Radio, & In-Vehicle Communications Capable. ROCKFORD FOSGATE Stage 3 Audio: (2) 6.5" 50W Front Co-axial Speakers & (2) 6.5" 50W Rear Co-axial Speakers, 4-Channel Amp w/ Fade, Automatic Volume Level, & 5-band Equalizer |
| Lighting | LED Headlight w/ Accent & LED Taillights |
| Seat Type | Bolstered Bucket Seats with Driver Seat Slider and Height Adjustable Seat Belts |
| Tilt Steering | Standard |
| Stealth Black Pursuit |
| Matte Ghost White Metallic |
| Black Crystal |
